Premium Block Plane

Add to Enquiry Bag

Enquire Now

Features

BLOCK PLANE
A Low angle plane with a fine adjustable mouth useful for adjusting miters, joining and fitting of doors and drawers. The mouth opening is easily adjusted for fine shavings. The sole is precision ground for flatness. Ductile castings and a thick blade eliminates chatter fitted with Brass cap and screws.

Need Expert Advice
-Call us-

+ 91 11 43118888

Technical Data

Plane No. ORD No. Total Length Blade Width Blade WT.
  INCH MM INCH MM Ordering No. Kg
#60.1/2 260600 6 150 1.3/8 35 260605 0.9
#9.1/2 260610 6 150 1.5/8 42 260615 1
#69.1/2 260630 6 150 1.5/8 42 260615 0.95
