| Ordering No. | Face Plate Diameter (D) | Base Diameter (D1) | Base Scroll Diameter (D2) | Table Thickness (T) | Body Heigth (H) | Table Heigth (H1) | Adjustable Heigth (H2) | Net Weight | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Min | Max | ||||||||||||||||
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Kgs | |
| 118030 | 5 | 125 | 5.1/8 | 130 | 4 | 100 | 3/8 | 9.5 | 7.3/4 | 198 | 6.5/8 | 170 | 9.1/4 | 235 | 13 | 330 | 6.5 |
