Enquire NowMade of highest quality Ductile Cast Iron . The Angles can be set in three dimensions . The 360º tunable base is graduated in degrees. The vise can be elevated through 90º from the horizontal to the vertical position, and it can also be tilted on its lower angle setting base up to 45º in both the left and right directions. The vise can be securely locked in all of its three settings.
| Ordering No. | Length (L) | Width (W) | Height (H) | Jaw Width (W1) | Jaw Opening (O) | Jaw Depth (D) | Base Length (L1) | Net Weight | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Kgs | |
| 110951 | 16 | 406 | 7.5/8 | 193 | 6.5/16 | 159 | 3.1/8 | 80 | 3.1/8 | 80 | 1.1/4 | 32 | 9.3/4 | 248 | 16.0 |
| 110952 | 18.1/8 | 460 | 9.5/8 | 245 | 7.1/2 | 190 | 4.5/16 | 110 | 4.1/2 | 115 | 1.1/2 | 38 | 12.3/16 | 310 | 25.0 |
| 110953 | 22.1/8 | 562 | 10 | 250 | 8 | 202 | 3.1/8 | 130 | 5.3/4 | 145 | 2 | 52 | 12.7/8 | 327 | 41.0 |
