Enquire NowCLAMP TYPE.
This Useful Portable Vice Can Be Attached To Most Working Surface By Means Of A 2 1/2 Inch Capacity.
This Vice Is Designed To Be Mounted Underneath The Bench, So That The Top Of Jaws Are Flush With The Bench Top. The Jaws Have Provision For Attachment Of Wooden Cheeks To Protect The Work Piece.
| Ordering No. | Length | Height | Jaw Width | Jaw Opening | Jaw Depth | Clamping Ds. | Net Weight Kgs. |
||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||
| 110217 | 8.3/4 | 220 | 3.3/8 | 85 | 6 | 150 | 5 | 125 | 2 | 50 | 4 | 100 | 2.86 |
| 110218 | 8.1/2 | 215 | 3 | 75 | 6 | 150 | 5 | 125 | 2.3/16 | 55 | 4.3/8 | 110 | 2.46 |
| 110219 | 10.3/16 | 255 | 4 | 100 | 7 | 175 | 6 | 150 | 2.1/2 | 110 | 4.3/8 | 110 | 3.16 |
