Enquire NowAs the name rightly suggests it has dual useage as a vee block and an angle plate. Having a single piece close grained cast iron construction, which ensures rigidity.
Castings are stress relived. Useful For Easy operations in set up jobs. The angle block is precision ground and has a parallelism of +/ - 0.005†(0.012mm ) and a squareness of + / - 0.005†(0.012mm ).
| Ordering No. | Dimensions | Net Weight Kgs. |
|||||
|---|---|---|---|---|---|---|---|
| Overall Length | Overall Width | Overall Height | |||||
| Inch | mm | Inch | mm | Inch | mm | ||
| 110380 | 3 | 75 | 3 | 75 | 5 | 125 | 2.50 |
| 110385 | 4 | 100 | 4 | 100 | 6 | 150 | 4.50 |
| 110390 | 5 | 125 | 5 | 125 | 7 | 175 | 7.50 |
| 110395 | 6 | 150 | 6 | 150 | 8 | 200 | 12.00 |
