| Ordering No. | Base Length (L) | Base width (W) | Table Dia. (D) | Table T-Slot Qty |
T-Bolt Size |
Overall Height(H) | Table Body Height (H1) |
Center Bore | Over All Length (L1) |
Center Height (CH) |
Body Height (H2) |
Tilt Body Height (H3) |
|||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||||
| 111325 | 6.3/4 | 172 | 5.5/8 | 142 | 4.5/16 | 110 | 3 | M8 | 4.9/16 | 116 | 2.7/8 | 72.2 | MT-2 | 9.3/4 | 248 | 3.1/4 | 82 | 1.13/16 | 46.2 | 6.7/16 | 164 |
| 111335 | 8.7/16 | 214 | 7.1/16 | 180 | 6 | 150 | 3 | M8 | 5 | 124 | 3.1/8 | 80 | MT-2 | 11.1/2 | 291.5 | 4.1/8 | 105 | 2 | 50 | 8 | 204 |
