Enquire NowWork can be quickly and correctly set at any angle with these adjustable angle plates. They are graduated for setting 0-90° and can be easily adjusted manually and locked in adjusted position by means of two locking nuts. For setting purposes, a degree scale, reading minimum one degree, is graduated on the base itself. This ensures better setting accuracy.
Swiveling face is provided with T-slots machined from solid. Other face is provided with cast cored slots for clamping the angle plate on machine table. Made from close grained Cast Iron. Casting stress relieved.
Working faces flat within 0.012 mm per 300 mm and square and parallel within ± 40.0 micron per 300mm in two extreme positions. Edges parallel and square within 0.05mm per 300mm.
Ordering No. | Size of Tables | Height | No. of T Slot | T Slot Sizes (A) |
Net Weight Kgs. |
||
---|---|---|---|---|---|---|---|
Inch | mm | Inch | mm | mm | |||
110315 | 5 x 6 | 125 x 150 | 4.1/2 | 112 | 3 | M-10 | 6.6 |
110320 | 6 x 8 | 150 x 200 | 5 | 125 | 3 | M-10 | 13.2 |
110325 | 8 x 10 | 200 x 250 | 6.1/2 | 162 | 3 | M-12 | 21 |
110330 | 10 x 12 | 250 x 300 | 7.1/2 | 187 | 4 | M-12 | 32 |
110331 | 10 X 15 | 300 X 380 | 8 | 200 | 4 | M-12 | 48 |
