Features

A multiuse reference tool for accurate machining work in tool rooms and in small production jobs for checking flatness, squareness and parallelism. Manufactured from solid alloy steel with a convenient step of 1.1/4” ( 32mm ) down from the top and a ½” (12mm) seat allowing for use with smaller work pieces. Tapped holes which are 24 in numbers allow fastenings to fixtures and clamping work to this angle plate very easy. Hardened to 58 TO 62 HRc. Square and parallel within 0.0002” per 4” length. (.005mm per 100mm ).

Note : when placing order kindly Confirm you need metric thread or impried thread.
