Enquire NowProvides a solid base for mounting vises, fixtures, or sub plates for convenient set-ups in inspection, tooling, and production. Manufactured from close grained cast iron. Castings are stress relieved. Precision ground flat and square having an accuracy in parallelism and squareness within + / - 0.0004” per 6” length ( + /- 0.01mm per 150mm ).
| Ordering No. | Overall Length | Overall Width | Overall Height | No. of Ribs |
Net Weight Kgs. |
|||
|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | |||
| 110410 | 1 | 25 | 1 | 25 | 1 | 25 | 1 | 0.250 |
| 110420 | 2 | 50 | 2 | 50 | 2 | 50 | 1 | 0.500 |
| 110425 | 3 | 75 | 3 | 75 | 3 | 75 | 1 | 1.200 |
| 110430 | 4 | 100 | 4 | 100 | 4 | 100 | 1 | 3.000 |
| 110435 | 5 | 125 | 5 | 125 | 5 | 125 | 1 | 5.500 |
| 110440 | 6 | 150 | 6 | 150 | 6 | 150 | 1 | 8.000 |
| 110445 | 8 | 200 | 8 | 200 | 8 | 200 | 2 | 16.000 |
| 110450 | 12 | 300 | 12 | 300 | 12 | 300 | 2 | 45.000 |
Set of 2 pcs
| Ordering No. | Overall Length | Overall Width | Overall Height | No. of Ribs |
Net Weight Kgs. |
|||
|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | |||
| 110411 | 1 | 25 | 1 | 25 | 1 | 25 | 1 | 0.500 |
| 110421 | 2 | 50 | 2 | 50 | 2 | 50 | 1 | 1.000 |
| 110426 | 3 | 75 | 3 | 75 | 3 | 75 | 1 | 2.400 |
| 110431 | 4 | 100 | 4 | 100 | 4 | 100 | 1 | 6.000 |
