Enquire NowManufactured from tool steel hardened 55-60 HRC., and high precision ground. The rapid positioning notches allow the vise to be locked in any position by means of a hex key provided with the vise.
‘V' Grooves in the sliding jaw both horizontal and vertical facilitate holding of round jobs. Jaw pressure on work piece is forward and downward for repeatable positioning and maximum holding power.
| Ordering No. | Length | Width | Height | Jaw Width | Jaw Opening | Jaw Depth | Net Weight Kgs. |
||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||
| 110100 | 2.1/2 | 63 | 1 | 25 | 1.1/8 | 28 | 1 | 25 | 5/8 | 16 | 3/8 | 10 | 0.25 |
| 110101 | 4 | 100 | 1 | 25 | 1.1/2 | 38 | 1 | 25 | 1.1/2 | 38 | 3/4 | 20 | 0.50 |
| 110102 | 6 | 150 | 1.1/2 | 38 | 1.1/2 | 38 | 1.1/2 | 38 | 3 | 75 | 3/4 | 20 | 1.00 |
| 110103 | 6.1/4 | 158 | 2 | 50 | 2 | 50 | 2 | 50 | 3.1/8 | 80 | 1 | 25 | 1.50 |
| 110104 | 7 | 178 | 3 | 75 | 2.1/4 | 57 | 3 | 75 | 4 | 100 | 1.1/2 | 38 | 3.50 |
| 110105 | 9.1/2 | 241 | 4 | 100 | 3.1/4 | 85 | 4 | 100 | 5.1/2 | 140 | 1.3/4 | 44 | 9.25 |
