Enquire NowManufactured from Tool Steel Hardened 55-60 HRC., and high precision ground. Screw type vise for clamping, releasing is through threaded spindle with precision cut square threads for smooth operation. Vise jaw movement is on dovetail slide for rigidity. Bottom of vise can be used as a long precision Vee block. This vise has multi uses.
Ordering No. | Length | Width | Height | Jaw Width | Jaw Opening | Jaw Depth | Base Length | Net Weight Kgs. |
|||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||
110125 | 12.1/2 | 315 | 2.1/2 | 63 | 2.3/4 | 70 | 2.1/2 | 63 | 2.1/8 | 55 | 1 | 25 | 7.5/8 | 195 | 5.00 |
