Enquire NowManufactured from tool steel hardened 55-60 HRC. High precision ground this vise has recessed pockets at both ends for clamping. There are Vees in the inside faces of jaws.
| Ordering No. | Length | Width | Height | Jaw Width | Jaw Opening | Jaw Depth | Net Weight Kgs. |
||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||
| 110120 | 7.1/4 | 184 | 2.7/8 | 73 | 2.3/4 | 70 | 2.3/4 | 73 | 3.3/4 | 95 | 1.3/8 | 27 | 4.00 |
| 110121 | 8.1/4 | 210 | 2.7/8 | 73 | 3 | 75 | 3 | 75 | 4.1/2 | 112 | 1.3/8 | 38 | 4.00 |
