Enquire NowMade of close grained high tensile cast iron. Jaws ground and Hardened 55±5 HRC. Swivel base provided with positive locking and adjustable through 360°. Automatically adjusts work piece to it's centre. Opposite threads for quick and accurate centering.
| Ordering No. | Length | Width | Height | Jaw Width | Jaw Opening | Jaw Depth | Base Length | Net Weight Kgs. |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||
| 110080 | 6.3/4 | 170 | 3.3/4 | 95 | 3.3/8 | 85 | 2 | 50 | 2 | 50 | 1 | 25 | 5.3/4 | 145 | 3.25 |
| 110081 | 10.1/4 | 260 | 6.1/2 | 165 | 5 | 125 | 4 | 100 | 4 | 100 | 1.1/2 | 40 | 9.1/4 | 235 | 15.00 |
| 110082 | 11.1/2 | 295 | 7.3/4 | 195 | 6 | 150 | 5 | 125 | 5 | 125 | 2 | 50 | 10.1/2 | 265 | 22.00 |
| 110083 | 14.7/8 | 377 | 9.1/4 | 235 | 6.5/16 | 160 | 6 | 150 | 6 | 150 | 2.3/8 | 60 | 11.5/8 | 295 | 30.00 |
| 110084 | 8.1/2 | 215 | 5.1/2 | 138 | 4.1/2 | 115 | 3 | 76 | 3 | 76 | 1.5/8 | 42 | 7.5/8 | 195 | 8.50 |
