Enquire NowMade of close grained high tensile cast iron. Jaws ground and hardened 55±5 HRC.
Automatically adjusts workpiece to it's center. Opposite threads for quick and accurate centering. This is a low profile vise.
| Ordering No. | Length | Width | Height | Jaw Width | Jaw Opening | Jaw Depth | Base Length | Net Weight Kgs. |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||
| 110085 | 12 | 304 | 6 | 150 | 3 | 75 | 3 | 75 | 5 | 127 | 1.3/8 | 35 | 10 | 255 | 7.00 |
| 110086 | 10.1/2 | 266 | 8 | 200 | 4.1/4 | 107 | 4 | 100 | 4 | 100 | 1.3/4 | 44 | 10.1/4 | 210 | 1.50 |
| 110087 | 6.3/4 | 170 | 3.3/8 | 85 | 2.3/8 | 60 | 2 | 50 | 2 | 50 | 1 | 26 | 4.3/4 | 120 | 2.20 |
