Enquire NowManufactured from heavy duty close grained high tensile seasoned cast iron, with precision rotary head four way block. Made of tool steel hardened & ground, Block hardness is 55±5 HRC. parallelism <0.015mm. Horizontal movement each side 0° to 90°, jaw block rotates on the axis. The jaw block can hold the circular job vertical and horizontal and also hold the flat job on flat surface. The 360° swivel base further allows rotation.
| Ordering No. | Length | Width | Height | Jaw Width | Jaw Opening | Jaw Depth | Base Length | Net Weight Kgs. |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||
| 110073 | 13.1/2 | 345 | 6.9/16 | 162 | 4.5/8 | 115 | 4 | 105 | 4 | 100 | 1.1/2 | 40 | 9.1/2 | 240 | 19.000 |
| 110074 | 16.1/2 | 445 | 8.3/4 | 220 | 6.1/4 | 160 | 6 | 150 | 6 | 150 | 2 | 50 | 11.5/8 | 295 | 46.000 |
| 110076 | 8.7/16 | 215 | 4.3/8 | 110 | 3.3/4 | 95 | 2.7/16 | 60 | 3.3/8 | 90 | 1.3/16 | 30 | 6 | 150 | 6.000 |
