PRECISION GRINDING CONTROL VISE

Add to Enquiry Bag

Enquire Now

Features

  • CHARACTERISTICS
  • Vise made of tool steel hardened and high precision ground 55-60 HRC., base is manufactured from close grained high tensile cast iron. Swivels on two levels 360° horizontal ±45° vertical nonious for precise minute read out. Screw for upward and downward swing. This vise is suitable for Grinding, Boring, Milling and Eroding.

Need Expert Advice
-Call us-

+ 91 11 43118888

Technical Data

Ordering No. Length Width Height Jaw Width Jaw Opening Jaw Depth Basic Length Net Weight
Kgs.
Inch mm Inch mm Inch mm Inch mm Inch mm Inch mm Inch mm
110090 7.5/8 195 4.1/4 108 5.1/2 140 2.3/4 70 3.1/4 82 1.1/4 32 7 180 12.00
