Enquire NowManufactured from graded cast iron. This vise has side faces which are fully ground allowing right angle positioning in 3 directions horizontal, vertical and straight.
| Ordering No. | Length | Width | Height | Jaw Width | Jaw Opening | Jaw Depth | Base Length | Slot clamping distance |
Net Weight Kgs. |
||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||
| 110155 | 9 | 230 | 5.1/2 | 143 | 2.1/2 | 63 | 3.1/8 | 80 | 3.1/8 | 80 | 1.3/16 | 30 | 6 | 155 | 4 | 102 | 3.500 |
| 110156 | 11 | 275 | 6.3/16 | 155 | 2.1/2 | 63 | 4 | 100 | 3.1/2 | 90 | 1.3/16 | 30 | 7.1/4 | 185 | 4.3/8 | 110 | 4.300 |
| 110157 | 13.3/8 | 335 | 7.3/16 | 180 | 2.3/4 | 70 | 4.3/4 | 120 | 4.3/4 | 120 | 1.3/16 | 30 | 8.5/8 | 220 | 5.3/8 | 135 | 7.000 |
