MILLING MACHINE VISE WITH SWIVEL BASE (Heavy Duty)

Add to Enquiry Bag

Enquire Now

Features

  • CHARACTERISTICS
  • Manufactured from close grained high tensile cast iron. Swivel is full 360°. This is very useful for heavy duty milling jobs. Vise is low height for maximum clearances. Jaws are fully ground & precision with parallelism of 0.0012" (30 microns) the hardness of jaws is 55±5 HRC.

Need Expert Advice
-Call us-

+ 91 11 43118888

Technical Data

Ordering No. Length Width Height Jaw Width Jaw Opening Jaw Depth Base Length Net Weight
Kgs.
Inch mm Inch mm Inch mm Inch mm Inch mm Inch mm Inch mm
110230 15 381 8 200 5 125 4 100 4 100 1.3/4 45 10.1/2 265 19.00
110231 19 482 10.1/2 267 5.3/4 146 6 150 6 150 2.3/16 55 12.7/8 325 39.00
110232 24.3/8 620 12 304 6.1/4 159 8 200 8 200 2.3/8 60 15.5/8 395 63.00
