Enquire NowManufactured from close grained cast iron. Hardened ground steel jaws prismatic profiles of 90°. The rugged design makes these vises perfect for even most difficult of drilling, tapping & reaming operations.
| Ordering No. | Length | Width | Height | Jaw Width | Jaw Opening | Jaw Depth | Base Length | Net Weight Kgs. |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||
| 110150 | 9.1/4 | 235 | 5.1/4 | 135 | 1.7/8 | 40 | 2.1/2 | 63 | 3 | 75 | 1 | 25 | 6 | 155 | 2.00 |
| 110151 | 11 | 280 | 6.1/8 | 155 | 2.1/8 | 55 | 3.1/8 | 80 | 3.3/4 | 95 | 1 | 25 | 7.1/4 | 185 | 4.00 |
| 110152 | 12.1/2 | 315 | 7.7/8 | 200 | 2.3/8 | 60 | 4 | 100 | 4.3/8 | 110 | 1.3/8 | 35 | 9.1/4 | 235 | 7.00 |
| 110153 | 16.1/4 | 410 | 8.5/8 | 220 | 3.3/8 | 85 | 5 | 125 | 5 | 125 | 1.7/8 | 45 | 11.5/8 | 295 | 13.00 |
| 110154 | 17.7/8 | 455 | 10.3/8 | 260 | 4.1/8 | 105 | 6 | 150 | 7.3/4 | 195 | 2 | 50 | 13.5/8 | 345 | 24.00 |
