Enquire NowManufactured from graded cast iron and precision ground. These vises have a needle bearing thrust collar. Vise jaws are in pairs and replaceable. Parallelism of 0.0012" (30 microns) the hardness of jaws is 55±5 HRC.
| Ordering No. | Length | Width | Height | Jaw Width | Jaw Opening | Jaw Depth | Base Length | Net Weight Kgs. |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||
| 110249 | 12.3/8 | 314 | 6.3/8 | 162 | 3.7/16 | 88 | 3.15/16 | 100 | 4.11/32 | 110 | 1.7/32 | 31 | 13 | 330 | 20.00 |
| 110250 | 18.1/2 | 470 | 8.7/8 | 225 | 4.3/4 | 120 | 6 | 150 | 7.3/16 | 180 | 1.3/4 | 45 | 16.3/8 | 415 | 33.00 |
| 110255 | 21 | 530 | 11.1/2 | 290 | 7 | 175 | 8 | 200 | 10 | 250 | 2 | 50 | 21 | 530 | 68.00 |
