Enquire NowMachine Vice made of Ductile cast iron Precision ground on all faces. The clamping holes to mount on milling machine or milling slide ,Rotary tables.
The jaws are vertical vee to hold round.
| Ordering No. | Round Dia | Total Length | Body Dia | Height | Jaw Width | Jaw Opening | Jaw Depth | Net Weight Kgs. |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||
| 110144 | 3 | 76 | 5.5/8 | 142 | 3.1/4 | 82 | 1.1/4 | 32 | 2.1/2 | 65 | 1.3/16 | 30 | 3/4 | 20 | 1.10 |
| 110145 | 4 | 100 | 6.5/8 | 168 | 4.3/16 | 106 | 1.1/4 | 32 | 3.5/16 | 84 | 1.5/8 | 40 | 3/4 | 20 | 1.30 |
