| Size | Carbon Steel Tap | Die Ø | |||||
|---|---|---|---|---|---|---|---|
| mm | pitch | Set of 3 Pcs | Single Ordering No. | Die | |||
| Ordering No. | I TAPER | II PLUG | III BOTTAM | Ordering No. | |||
| 3 | 0.5 | 141200 | 141202 | 141204 | 141206 | 141208 | 13/16" |
| 4 | 0.7 | 141210 | 141212 | 141214 | 141216 | 141218 | 13/16" |
| 5 | 0.8 | 141220 | 141222 | 141224 | 141226 | 141228 | 13/16" |
| 6 | 1.0 | 141230 | 141232 | 141234 | 141236 | 141238 | 13/16" |
| 7 | 1.0 | 141240 | 141242 | 141244 | 141246 | 141248 | 1" |
| 8 | 1.25 | 141250 | 141252 | 141254 | 141256 | 141258 | 1" |
| 9 | 1.25 | 141260 | 141262 | 141264 | 141266 | 141268 | 1" |
| 10 | 1.5 | 141270 | 141272 | 141274 | 141276 | 141278 | 1" |
| 11 | 1.5 | 141280 | 141282 | 141284 | 141286 | 141288 | 1" |
| 12 | 1.75 | 141290 | 141292 | 141294 | 141296 | 141298 | 1" |
| 14 | 2.0 | 141300 | 141302 | 141304 | 141306 | 141308 | 1.5" |
| 16 | 2.0 | 141310 | 141312 | 141314 | 141316 | 141318 | 1.5" |
| 18 | 2.5 | 141320 | 141322 | 141324 | 141326 | 141328 | 1.5" |
| 20 | 2.5 | 141330 | 141332 | 141334 | 141336 | 141338 | 1.5" |
| 22 | 2.5 | 141340 | 141342 | 141344 | 141346 | 141348 | 1.5" |
| 24 | 3.0 | 141350 | 141352 | 141354 | 141356 | 141358 | 1.5" |
| 25 | 3.0 | 141360 | 141362 | 141364 | 141366 | 141368 | 2" |
| 27 | 3.0 | 141370 | 141372 | 141374 | 141376 | 141378 | 2.1/4" |
| 30 | 3.5 | 141380 | 141382 | 141384 | 141386 | 141388 | 2.1/4" |
| 33 | 3.5 | 141390 | 141392 | 141394 | 141396 | 141398 | 2.1/4" |
| 36 | 4.0 | 141400 | 141402 | 141404 | 141406 | 141408 | 3" |
| 38 | 4.0 | 141410 | 141412 | 141414 | 141416 | 141418 | 3" |
| 40 | 4.0 | 141420 | 141422 | 141424 | 141426 | 141428 | 3" |
| 42 | 4.5 | 141430 | 141432 | 141434 | 141436 | 141438 | 4" |
| 45 | 4.5 | 141440 | 141442 | 141444 | 141446 | 141448 | 4" |
| 50 | 5.0 | 141450 | 141452 | 141454 | 141456 | 141458 | 4" |
