| Ordering No. |
Dia of Body |
Total Head Heigh |
Minimum Cap |
Max Cap | Tool Shank Dia (H7) |
Distance Between Tool Housaxes |
Minimum Carriage Movement (Radial) |
Radial Movement for one Graduation of the Vernier |
Automatic Feed (Radial) for Rev |
No of Tool Position for Vertical too |
Net.Weight Kg. |
||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||||
| 171220 | 2-3/8 | 60 | 3-1/8 | 78.5 | 1/8 | 3 | 10 | 250 | 1/2 | 12 | 23/32 | 18 | 3/4 | 20 | .0004 | 0.01 | 0.05-0.10 | 3 | 2.50 |
| 171240 | 3-9/16 | 90 | 4 | 100 | 3/16 | 5 | 14 | 350 | 3/4 | 20 | 1 | 25 | 1-3/16 | 30 | .0004 | 0.01 | 0.05-0,10-0,15 | 3 | 6.50 |
